China Smooth Geocell Machine Manufacturers, Suppliers, Factory

The most important part of Soft Pvc Sheet Extruder Machine Turtle Pattern Machine is the three-roller forming machine, which has two smooth rollers and a tortoise shell roller in the middle.The processing procedures of the tortoise shell roller include: rough turning, dynamic balancing, fine turning, grinding, electroplating, engraving, frosting, and fine mirror grinding. The time for engraving the roller is relatively long, so the delivery cycle of the whole equipment is relatively long. Manufacturers who need to process and customize tortoise shell equipment must place orders in advance.

Based in China, Eaststar is a prominent supplier of Seedling Tray Seeder Making Machines. These machines are meticulously crafted to meet the demands of nurseries and agricultural enterprises. Eaststar's state-of-the-art factory employs cutting-edge technology to manufacture high-quality equipment. Collaborating with trusted suppliers, Eaststar ensures the use of top-notch components, ensuring the efficiency and durability of their machinery. With a reputation for advanced technology and reliable production capabilities, Eaststar is a preferred choice for suppliers worldwide in need of top-grade Seedling Tray Seeder Making Machines.

Soft Pvc Sheet Single Screw Extruder Making Machine : The equipment mainly consists of a 120 single screw extruder, a three-roller calender, a cooling bracket, a rubber roller traction machine, a shearing machine, and a conveyor belt device. The standard width of the PVC turtle back panel equipment product is 1000mm. The thickness is 6mm. PVC antistatic extruder board equipment can produce various textures such as turtle pattern, orange peel pattern, and checkered pattern. PVC turtle board equipment can be processed and customized according to customer requirements.

Seed Tray Vacuum Forming Machine technical parameter Specification width of used sheet: 300~320mm, thickness: 0.8~2mm. Forming area (maximum): 400*600 mm, working efficiency of 15~20 times / minute. Power used: three-phase four-wire 380 volts, maximum power 25KW Hydraulic pressure: 100T External size (mm) length, width and height) 3600mm*980mm*1500mm

Plant Transplant Root Control Board Equipment is mainly in accordance with the working principle of hot pressing equipment design. Root control equipment can also produce water spraying sheets 1. PET Root Plant Root Protection Equipment is mainly in accordance with the working principle of hot pressing equipment design, process is: sheet —— feeding —— heating —— pressing —— pressure —— molding —— cutting steps, appearance neat and practical, plate processing all processing center, ensure the accuracy of all hole size, column and pin appearance are hard chromium quenching treatment, ensure the sliding and wear resistance, machine system edited into manual and automatic two parts, in manual case all action can be single operation. 2: The feed motor is driven by a servo motor with a power of 2 kW. 3: feeding reducer motor 0.55KW and 1:10 special reducer, to ensure the stability of feeding speed! 4: Ceramic heating block: new ceramic heating block, heating fast and low power consumption, the temperature can be adjusted freely, according to the thickness of different materials. 5: Other mechanical parts are produced and processed by our company. Automatic control system adopts: Delta PLC control, 6: The machine adopts hydraulic balanced distribution design, the overall balance is better, to solve the situation of the high and low in the production to prolong the use time of the mold.

PE PP Control Root Board Making Machine with the working principle of hot pressing equipment design. PE PP Control Root Board Making Machine can also produce water spraying sheets 1. PET Root Plant Root Protection Equipment is mainly in accordance with the working principle of hot pressing equipment design, process is: sheet —— feeding —— heating —— pressing —— pressure —— molding —— cutting steps, appearance neat and practical, plate processing all processing center, ensure the accuracy of all hole size, column and pin appearance are hard chromium quenching treatment, ensure the sliding and wear resistance, machine system edited into manual and automatic two parts, in manual case all action can be single operation. 2: The feed motor is driven by a servo motor with a power of 2 kW. 3: feeding reducer motor 0.55KW and 1:10 special reducer, to ensure the stability of feeding speed! 4: Ceramic heating block: new ceramic heating block, heating fast and low power consumption, the temperature can be adjusted freely, according to the thickness of different materials. 5: Other mechanical parts are produced and processed by our company. Automatic control system adopts: Delta PLC control, 6: The machine adopts hydraulic balanced distribution design, the overall balance is better, to solve the situation of the high and low in the production to prolong the use time of the mold.
